The TBS-1000 from Tanbos is a revolutionary vehicle-mounted cable fault location system engineered for high-voltage power networks. Integrating multiple fault detection technologies—including Time-Domain Reflectometry (TDR), Arc Reflection Method (ARM), Impulse Current Decay (ICE), and DC Testing—it provides an all-in-one, operator-safe testing environment. With its Auto Go™ Android-based control software and wireless tablet interface, the system automates the fault detection process, analyzing cable conditions, detecting waveform anomalies, and guiding users step-by-step through fault pre-location. Its fully insulated high-voltage section and built-in emergency safety measures ensure top-tier reliability in any utility or industrial setting.

Applications:

• Underground cable fault diagnostics for medium and high-voltage systems
• Fault location and verification in urban power networks and substations
• Electrical maintenance and pre-commissioning for distribution utilities
• Rapid and automated transient and permanent fault detection
• Suitable for installation in service vehicles for mobile field testing

Specifications:

High Voltage Section:

• DC Test Range: 0–32kV
• Surge Output Levels: 8kV, 16kV, 32kV
• Energy Discharge: 2,432J across all levels
• Discharge Rate: Adjustable 3–10s or single-shot
• Capacitor: 76µF
• Voltage Cable Capacity: 0–500kV adjustable
• Ground Detection: 2–10Ω, Accuracy: ≤0.2Ω
• Step Voltage Detection: 0.5–200V peak, Accuracy: ≤0.2V
• Protection: Fully insulated, remote stop, ground verification
• Power Supply: 220V AC, 50/60Hz, 2kW
• Size: 900 × 650 × 703 mm
• Weight: 180kg
• IP Rating: IP43
• Operating Temp: -20°C to +45°C

Radar and Control Unit:

• Control: Wireless tablet (Android, 11.5″ display)
• Pulse Width: 50ns–10µs
• Range: Up to 100km @ 80m/µs
• Resolution: 0.1m
• Accuracy: 0.10%
• Gain: 0–40dB
• Multishot Support: Yes (5 HV traces)
• Storage: Unlimited waveform storage
• Communication: Wi-Fi 2.4GHz

Standard Accessories:

• Control Box
• 10m HV Output Cable
• 10m Ground Cable
• 10m Ground Condition Detection Cable
• 5m Control Cable
• Android Tablet (not included for export due to restrictions)

Optional Accessories:

• 50m Electric Cable Reel Kit (HV output cable, ground cable, F-U connect cable)
• LB4-60A Smart Bridge for fault burning and bridge location
• PS4800 Power Bank for portable operation
• PP20 Pin-Pointer for precise acoustic fault localization
• HCI Cable Identifier for target cable confirmation
• Discharge Rod for safe system discharge

About Manufacturer

Founded in 2008, Xianheng intl (Tanbos) is a leading developer and manufacturer of portable and rugged test equipment for electrical systems and substations in China. Their tools focus on safety, speed, and cost-efficiency. Tanbos is listed on the Shanghai Stock Exchange and has built lasting partnerships across America, Europe, Southeast Asia, Africa, and the Middle East.
