The MobilePV-BESS Fully Automated Station is an advanced off-grid power generation and storage solution from WELTRUS. Combining high-output mobile PV arrays with scalable lithium battery energy storage, it delivers clean, reliable, and independent electricity in locations without grid access. This system’s automated folding solar rack enables fast setup and relocation, making it perfect for industries, military, emergency relief, and rural electrification projects. With its modular 100kWh hybrid BESS units and integrated inverter system, the MobilePV-BESS ensures 24/7 power availability through solar generation, battery storage, and optional diesel generator backup.

Specifications:

PV Rack System

Parameter	56.64kWp Model	88.32kWp Model
Total Weight	12,000 kg	17,000 kg
Solar Capacity	96 × 590Wp panels	192 × 460Wp panels
Folded Dimensions (L×W×H)	5200 × 2290 × 2064 mm	5500 × 2290 × 2547 mm
Unfolded Dimensions (L×W×H)	60,000 × 5200 × 1000 mm	89,000 × 5500 × 1100 mm
Max Unfolding Speed	1–9 m/min	1–9 m/min
Motor Drive Power	1.5 kW × 1 set	1.5 kW × 2 sets
Logistics	Fits in 20ft container	Fits in 40ft HQ container

Hybrid BESS (per unit)

• Battery Type: LFP
• Capacity: 100kWh
• Hybrid Inverter: Integrated for PV + storage + diesel generator operation
• Scalability: Multiple BESS units for larger capacity requirements



Typical Applications:

• Off-grid villages and island microgrids
• Remote mining and industrial sites
• Military bases and defense operations
• Emergency disaster relief and reconstruction
• Agricultural irrigation and water management
• Temporary housing and modular communities
• Oil fields and energy company deployments
• Remote EV charging stations
• Outdoor events and large-scale gatherings

Packing List:

• Mobile PV rack system (selected model)
• 100kWh Hybrid BESS unit(s) with inverter
• Control and monitoring systems
• Installation manual & warranty documents

About Manufacturer:

WELTRUS (Hangzhou Weltrus New Energy Technology Co., Ltd.) is part of the Welfull Group, established in 1993, with an annual operating income exceeding 5.6 billion yuan. The company leverages its strong industrial and financial foundation in Zhejiang Province, China. It stands at the forefront of clean energy development with core competencies in photovoltaics, new energy vehicles, and energy storage applications. R&D & Innovation: Weltrus brings extensive R&D experience across several sectors—including energy storage, photovoltaic technology, new energy vehicle systems, and HVAC/R. This deep technical expertise drives continuous product innovation and upgrades.
