Safety Testers

ES9030 RCD Tester

  • Comprehensive RCD Testing: Measures trip time (0–999ms), trip current (1–1200mA), and voltage (1–1000V) for leakage protectors.
  • High Accuracy:
    • Voltage: ±3% ±3 digits (0.1V resolution).
    • Current: ±3% ±5 digits (1mA resolution).
  • User-Friendly:
    • Full-color touchscreen LCD (108mm×65mm) with backlight.
    • 500-data storage and USB transfer for analysis.
  • Portable & Safe:
    • 12.6V Li-ion battery (15-minute auto-shutdown).
    • Complies with IEC61010-1 (CAT III 600V).

Share This Product :

The ES9030 is a professional tester for residual current devices (RCDs), designed for electricians, construction safety inspectors, and power utilities. It features manual/auto testing modes, real-time battery monitoring, and IP54-rated durability, making it ideal for field use in construction, mining, and industrial applications.
Specifications
Measurement Capabilities
  • Voltage: 1.0–1000V (±3% accuracy).
  • Trip Current: 1–1200mA (±3% accuracy).
  • Trip Time: 0–999ms (±3% accuracy).
Technical
  • Power: 12.6V/2500mAh Li-ion.
  • Interfaces: USB for data transfer.
  • Display: 5-inch color touchscreen.
  • Safety:
    • 1000V AC withstand voltage.
    • IP54 rated (dust/water resistant).
  • Environmental:
    • Operating: -10°C–40°C, ≤80% RH.
    • Storage: -10°C–60°C, ≤70% RH.
Physical
  • Dimensions: 240mm × 188mm × 85mm.
  • Weight: 1100g (host), 190g (test leads).
About Manufacturer
Fuzrr Technology (Guangzhou Zhengneng Electronic Technology Co., Ltd) is a professional manufacturer engaged in R&D, production, and sales. The factory is located in Guangzhou, the metropolis of China’s International Greater Bay Area Economic Circle, near Hong Kong, Macau, and Shenzhen in the south. The company specializes in electrical safety testers, utility locators, and power quality instruments, exporting to 80+ countries. With 15+ years of experience, Fuzrr operates automated production lines with 100+ skilled workers and offers OEM/ODM services. Its R&D team provides robust technical support for global projects.
