Relay Test Set

Relay Test Set AVO Multi AMP PITS

Share This Product :

AVO / Multi-Amp MS-2 High Current Test Set AVO / Multi-Amp MS-2 Features:
  • Portable High Current Test Set
  • Digital Memory Ammeter: High-accuracy, direct-reading instrument with ?read-and-hold? memory for measurement of short duration currents
  • Digital, Multi-Range Timer: Crystal-controlled, high-accuracy instrument with autoranging? measures operating time to one millisecond
  • High-Output Current: Will provide 750 amperes through a 125 ampere breaker
  • Rugged and Lightweight: Weighs only 33 lbs. (15kg) and is tough enough to withstand daily field or plant use
  • Solid -State Output Initiate Circuit: Completely solid-state circuit eliminates need for contact maintenance
Specs:
  • Input (specify one): 120 volts OR 240 volts, 50/60 Hertz single-phase
  • Output Ranges:?0 to 120 volts at 5 amperes?0 to 24 volts at 25 amperes?0 to 6 volts at 120 amperes?0 to 3 volts at 240 amperes
  • Output Capacity:?The test set is capable of testing the time delay characteristics of devices rated up to 125 amperes using a test current of three times their rating (375 amperes). ? Additionally, to perform an instantaneous trip test, it will provide 750 amperes through a typical, 125-ampere, molded-case circuit breaker connected with the test leads provided with the test set
  • Ammeter:?Display: 3?-digit?Ranges (switch-selected): 0 to 1.999/19.99/199.9/750 amperes
  • Timer:?Display: 5-digit?Ranges: (switch-selected):?A. 0 to 99.999 seconds?B.? 0 to 999.99 seconds?C.? 0 to 99999 cycles
  • Timer Control Circuit:?A.? Current Actuated?B.? Normally Closed?C.? Normally Open

No additional information.
